Hertz HCP4DK Compact Power 2000W 4CH High Power D-Class Four Channel Amplifier

Contact us for more information

SKU:HCP4DK


The new HCP 4DK features latest generation D-Class 2Ω stable output stage reaching the impressive max power of 2000 W with the excellent S/N ratio of 105 dB. Extremely versatile, complete in its functions, provided with Speaker-In and RCA-In inputs to work with any head units, it has been designed to work also in mono (selectable mode), for a three-channel system with sub and front, or a powerful two-channels system. All the Hertz Compact Power amplifiers are assembled with high-quality components and feature a complete and by-passable crossover system. The dissipation system is optimized with the heat being transferred to the heat sink and then dissipated through the sides of the amplifier.

Data table

Channel mode4 - 3 - 2
Output Power (RMS)
@ 14.4 VDC
4 Ch: 150 W x 4 (4 ?)
4 Ch: 250 W x 1 (2 ?)
3 Ch: 150 W x 2 (4 ?) + 520 W x 1 (4 ?)
3 Ch: 250 W x 2 (2 ?) + 520 W x 1 (4 ?)
2 Ch: 520 W x 2 (4 ?)
Filters
Bypass
Hi-Pass
Lo-Pass
Band-Pass
Subsonic

Yes
A/B: 50 / 3.2k Hz @ 12 dB/Oct.
A/B: 50 / 3.2k Hz @ 12 dB/Oct.
-
No
Distortion - THD
(100Hz @ 4?)
0.03%
S/N Ratio
(A weighted @ 1V)
105 dB
Damping factor
(100Hz @ 4?)
200
Size W x D x H
mm (in.)
315 x 190 x 50 (12.40 x 7.48 x 1.97)

More Information

More Information
Dimensions 315 x 190 x 50mm
SKU HCP4DK
Brand HERTZ
