JL Audio W0v3 Series 12" Subwoofer 4-Ohm 12W0v3-4

SKU:12W0V3-4

RRP $249.99
$227.00
SAVE $22.99 (9%)


Calculate Shipping

You simply won’t find a better performing woofer in its price class!

The term ”overbuilt” gets thrown around a lot, but in the case of the W0v3’s, it actually applies. With beefy 2.0 or 2.5-inch voice coils and our innovative Elevated-Frame Cooling technology, they’re certainly capable of handling power. Proprietary DMA-Optimized motor systems offer best-in-class excursion capability, with increased output and better sound quality.

In simple terms, when the going gets loud, the W0v3’s are built to perform like no other woofers in their price class, making them the “go to” choice for those seeking high performance from an affordable subwoofer system.

You simply won’t find a better performing woofer in its price class!

W0v3 12-inch Subwoofer (300 W, 4 ?)

The 12W0v3 is a rugged performer with excellent efficiency, excursion capability and linearity. Its overall performance envelope that puts it right at the top of its price class. It features a beefy 2 in. diameter voice coil and our Elevated Frame Cooling design for enhanced power handling and reliability.

The 12W0v3 is best used with amplifier power in the 75W - 300W range and is optimized to operate in a moderately sized 1.375 cu. ft. (38.9 l) sealed enclosure, or a 1.75 cu. ft. (49.6 l) ported enclosure.

Features

  • Continuous Power Handling (RMS): 300 W
  • Recommended Amplifier Power (RMS): 75 - 300 W
  • Nominal Impedance (Znom): 4 Ω
  • Nominal Diameter: 12.0 in / 300 mm
  • Overall Diameter (A): 12.52 in / 318 mm
  • Mounting Hole Diameter (B): 11.0625 in / 281 mm
  • Bolt Hole Circle Diameter (C): 11.7 in / 297 mm
  • Motor Outer Diameter (D): 5.05 in / 128 mm
  • Mounting Depth (E): 5.40 in / 137 mm
  • Driver Displacement: 0.048 cu ft / 1.36 L
  • Net Weight: 8.11 lb / 3.68 kg
  • Free Air Resonance (Fs): 28.43 Hz
  • Electrical “Q” (Qes): 0.715
  • Mechanical “Q” (Qms): 10.709
  • Total Speaker “Q” (Qts): 0.67
  • Equivalent Compliance (Vas): 2.530 cu ft / 71.64 L
  • One-Way Linear Excursion (Xmax)*: 0.45 in / 11.4 mm
  • Reference Efficiency (no): 0.22%
  • Efficiency (1 W / 1 m)**: 85.64 dB SPL
  • Effective Piston Area (Sd): 74.509 sq in / 0.0481 sq m
  • DC Resistance (Re): 4.280 Ω
More Information
Woofer Diameter (mm) 300mm
Woofer Diameter (Inch) 12 Inch
Mounting Diameter 281mm
Shallow Mount No
Woofer Mounting Depth 137mm
RMS Power 300WRMS
Voice Coil Single Voice Coil
Impedance 4 Ohm
Sensitivity (dB) 85.64dB
Sealed Box Volume 1.375 cu/ft (38.94-litres)
SKU 12W0V3-4
Brand JL AUDIO
