All-around performance in small enclosures at medium power levels.
W3v3 subwoofers offer phenomenal performance in medium power applications, without requiring a large enclosure.
This latest generation of W3 drivers benefits from a whole suite of advanced technologies originally developed for our flagship W7 subwoofers. A DMA-optimized motor system permits long, linear excursion capabilities, with minimal distortion and increased output, while multiple patented technologies enhance performance and reliability. These advances make these W3’s the best sounding, most reliable yet.
A mineral-filled, polypropylene, upper cone body with a metallic JL Audio logo medallion provides a simple, classy look. A removable (and customizable) mounting flange trim ring receives grille-mesh inserts (sold separately) directly, without the need for additional grille hardware.
All W3v3 subwoofers are built to exacting quality standards in our Miramar, Florida factory with global components and are offered in five sizes, ranging from 6.5-inch to 13.5-inch nominal diameters.
W3v3 8-inch Subwoofer (250 W, 4 ?)
If you need an 8-inch subwoofer that can create outstanding bass in extremely small enclosures, the 8W3v3 will do the job and surprise you with its power and accuracy. It employs the same technologies as its larger diameter brethren to deliver a whopping 0.375 in. (10 mm) of controlled, one-way, linear excursion.
The 8W3v3-4 is best used with amplifier power in the 75W - 250W range and is optimized to operate in a tiny 0.30 cu. ft. (8.5 l) sealed enclosure, or a 0.35 cu. ft. (9.9 l) ported enclosure.
Features
- Continuous Power Handling (RMS): 250 W
- Recommended Amplifier Power (RMS): 75- 250 W
- Nominal Impedance (Znom): 4 Ω
- Nominal Diameter: 8.0 in / 200 mm
- Overall Diameter (A): 8.54 in / 217 mm
- Mounting Hole Diameter (B): 7.09 in / 180 mm
- Bolt Hole Circle Diameter (C): 7.85 in / 199 mm
- Motor Outer Diameter (D): 4.75 in / 121 mm
- Mounting Depth (E): 4.63 in / 118 mm
- Driver Displacement: 0.03 cu ft / 0.85 L
- Net Weight: 8.2 lb / 3.7 kg
- Free Air Resonance (Fs): 35.14 Hz
- Electrical “Q” (Qes): 0.501
- Mechanical “Q” (Qms): 7.071
- Total Speaker “Q” (Qts): 0.467
- Equivalent Compliance (Vas): 0.54 cu ft / 15.29 L
- One-Way Linear Excursion (Xmax)*: 0.375 in / 10.0 mm
- Reference Efficiency (no): 0.13%
- Efficiency (1 W / 1 m)**: 83.24 dB SPL
- Effective Piston Area (Sd): 32.02 sq in / 0.021 sq m
- DC Resistance (Re): 3.77 Ω
Woofer Diameter (mm) | 200mm |
---|---|
Woofer Diameter (Inch) | 8 Inch |
Mounting Diameter | 180mm |
Shallow Mount | No |
Woofer Mounting Depth | 118mm |
RMS Power | 250WRMS |
Voice Coil | Single Voice Coil |
Impedance | 4 Ohm |
Sensitivity (dB) | 83.24dB |
Sealed Box Volume | 0.3 cu/ft 8.5-litres) |
SKU | 8W3V3-4 |
Brand | JL AUDIO |
