JVC CS-ZX6940 drvn 6x9 4-Way Coaxial Speakers

SKU:CS-ZX6940

$159.00


Calculate Shipping

At Automotive Superstore, we guarantee the most competitive pricing!

Seen a better price or just want a better price? Use "Make an Offer" All you need to do is create an account and submit your offer!



JVC CS-ZX drvn 15 x 23cm (6'' x 9'') 4-Way Coaxial Speakers

  • 4-Way Coaxial
  • 550W Peak/80W RMS Power
  • Frequency Response: 35 - 25,000Hz
  • Sound Pressure Level: 91dB/W.m
  • Crossover Frequency: TBA
  • Carbon Mica 3D Cone Woofer
  • 66mm (2-5/8'') Poly-Ether Imide Cone Midrange
  • Poly-Ether Imide Dome Tweeter
  • Poly-Ether Imide Dome Super Tweeter
  • Ferrite Magnet (Woofer/Midrange)
  • Single Roll Rubber Surround
  • Mounting Depth: 80.5mm (3-3/16")

Specifications

Woofer
Size15 x 23 cm (6" x 9")
Type4-Way Coaxial
DiaphragmCarbon Mica 3D Cone
SurroundSingle Roll Rubber Surround
MagnetFerrite Magnet
Midrange
Size6.6 cm (2-5/8")
DiaphragmPoly-Ether Imide Cone
MagnetFerrite Magnet
Tweeter
Size2.5 cm (1")
DiaphragmPoly-Ether Imide Dome
Super Tweeter 1
Size1.5 cm (19/32")
DiaphragmPoly-Ether Imide Dome
General
Frequency Response35 - 25,000Hz
Power Handling Capacity (RMS)80W
Power Handling Capacity (Peak Power)550W
Impedance4 ohms
Sound Pressure Level91dB/W.m
Crossover FrequencyTBA
Weight1.73kg (3.9 lbs)
 Magnet Mass570g (20.1 oz)
Mounting Depth80.5mm (3-3/16")

Features

JVC CSZX drvn 15 x 23cm (6'' x 9'') 4-Way Coaxial Speakers

More Information

More Information
Pair or Single Pair
Speaker Type Co-axial
Speaker Setup 3-Way
Woofer Diameter (mm) 163 x 234.8mm
Woofer Diameter (Inch) 6x9 Inch
Mounting Diameter 144.6 x 217.5mm
Woofer Mounting Depth 81mm
Tweeter Diameter (mm) 25mm
Tweeter Diameter (Inch) 1 Inch
Mid Diameter (Inch) 2.62 Inch
Mid Diameter (mm) 66mm
RMS Power 80W
Impedance 4 Ohm
Grilles Included Included
Sensitivity (dB) 91dB
Frequency Response 35Hz - 25kHz
SKU CS-ZX6940
Brand JVC
