Stinger SPXSH440 SwitchHUB 4 Channel Solid State Relay

Stinger SwitchHUB is a solid-state, high current relay block with 4 independent outputs

Control Your Devices Without Noise

Simplify your installation with the Stinger SWITCHHUB (SPXSH440) solid state relay.

Replace up to 4 typical mechanical relays with one easy to wire solid state relay block saving on extra wiring, additional harnesses and not to mention, a better connection.

Solid state relays operate silently and produce very little interference vs conventional mechanical relays which can also fail after excessive use.

Direct Control Where You Need It

Each output of the Stinger SWITCHHUB (SPXSH440) features thermal overload and short circuit protection offering superior protection of your connected equipment.

With built-in LED indicators, you can easily see thermal overload, active/inactive devices.

Each relay channel can be controlled via negative low current or positive low current input.

Made for Stinger SPX

Designed for use with the Stinger SPXM1 2.7" Powersports media centre for direct remote control of devices from the headunit itself.

High Amperage Control

With its solid-state design, the Stinger SWITCHHUB (SPXSH440) offers multiple power outputs eliminating the clutter of multiple high current replays and accompanying wiring.

Featuring

• 1x 40 Amp Terminal
• 3x 20 Amp Terminals

For a total of 100 Amp continuous output.

What Do You Get?

Each Stinger SPXSH440 Includes

• 1x SPXSH440 Relay Bank
• 1x Quick Start Guide

Features

• 1x 40 Amp Output
• 3x 20 Amp Output
• 4x Negative Trigger Inputs
• 4x Positive Trigger Inputs
• Active/Inactive Status LEDs
• Thermal / Short circuit Status LEDs
• Precision Grub Screw Terminals
• IPX6 Rated Construction
• Off-Road Ready
• Marine Grade

PLEASE NOTE:

1. Negative OR positive trigger per channel. Cannot be used at same time.

Specifications:
